Python如何对接Android API?

Of course! This is a very common question for developers looking to leverage Python's strengths in an Android environment. The term "Python Android API" can mean a few different things, so let's break down the main approaches, from the most popular to the more specialized.

Python如何对接Android API?-图1
(图片来源网络,侵删)

Here’s a comprehensive guide to using Python on Android.


The Short Answer: There is No Official "Python for Android API"

Google does not provide an official, first-party Python runtime or API for Android. Android's primary development language is Kotlin (and historically Java), with deep integration with the Android SDK.

However, the community and several companies have created robust solutions to run Python code on Android and interact with the system. These solutions provide their own APIs and methods to achieve this.

Here are the most popular methods, categorized by their approach.

Python如何对接Android API?-图2
(图片来源网络,侵删)

Kivy (Cross-Platform Framework)

This is the most popular and mature framework for building native-looking applications entirely in Python that run on Android, iOS, Windows, macOS, and Linux.

How it Works: Kivy includes its own set of UI widgets and a graphics engine. It bundles its own Python interpreter and the necessary libraries into the Android APK. It does not use the native Android UI components; instead, it draws its own UI on top of a OpenGL canvas.

The "API" for Android Interaction: Kivy provides a dedicated android module that gives you access to specific Android features.

Key Features:

  • Cross-Platform: Write your app once, deploy it everywhere.
  • Custom UI: You have complete control over the look and feel. It's not bound by Material Design or Human Interface Guidelines unless you build it that way.
  • Rich Graphics: Excellent for apps that require heavy graphics, animations, or multi-touch interfaces (e.g., games, data visualization tools).
  • Open Source: Licensed under the MIT license.

How to Access Android Features (The Kivy Way): You use the android module, which is only available when running on Android.

# main.py
from kivy.app import App
from kivy.uix.button import Button
def on_android_button_press(instance):
    # This code only runs on Android
    from android import activity, config
    import jnius # For more advanced Java interaction
    # Show a toast message
    activity.bind(on_activity_result=on_activity_result)
    activity.start_activityForResult(
        jnius.autoclass('android.content.Intent').newAction(
            jnius.autoclass('android.provider.Settings').ACTION_SETTINGS),
        42)
def on_activity_result(request_code, result_code, intent_data):
    print(f"Activity result: {request_code}, {result_code}")
class MyApp(App):
    def build(self):
        btn = Button(text='Press me for Android Settings')
        btn.bind(on_press=on_android_button_press)
        return btn
if __name__ == '__main__':
    MyApp().run()

To Build for Android: You use a tool called Buildozer. It automates the entire process of setting up a Python environment, bundling your app, and compiling it into an APK.

  1. Install Buildozer: pip install buildozer
  2. Navigate to your project directory.
  3. Run buildozer init to create a buildozer.spec file.
  4. Edit the .spec file to configure your app (name, orientation, permissions, etc.).
  5. Run buildozer android debug to build and run the APK on a connected device/emulator.

Best for: Games, creative apps, data visualization tools, or any app where a custom UI is a priority over native look-and-feel.


BeeWare (Cross-Platform Toolchain)

BeeWare is a suite of tools and libraries for building native applications in Python. Its flagship project is Toga, a GUI toolkit.

How it Works: Toga's goal is to use the native UI widgets of each platform. On Android, it uses the native Android SDK to create buttons, labels, text inputs, etc. This means your app will look and feel like a standard Android app.

The "API" for Android Interaction: The interaction is more abstract. You write your app using the Toga API, and Toga's backend handles the translation to the native Android calls.

Key Features:

  • Native Look-and-Feel: Your app uses the platform's native widgets.
  • Write Once, Deploy Everywhere: The same Python code can target Android, iOS, macOS, Windows, Linux, and even web browsers (using WebAssembly).
  • Comprehensive Widgets: Toga provides a wide range of UI components.
  • Open Source: Licensed under the Apache 2.0 license.

How to Access Android Features (The BeeWare Way): You interact with platform-specific features via briefcase plugins or by accessing the underlying Java APIs using a bridge like chiper.

# main.py
import toga
from toga.style import Pack
from toga.style.pack import COLUMN, CENTER
def button_handler(widget):
    # This is a Toga button handler
    print("Button pressed!")
    # To access Android-specific features, you would typically use a plugin
    # or a lower-level bridge like chiper.
def build(app):
    box = toga.Box(style=Pack(direction=COLUMN, alignment=CENTER, padding=20))
    label = toga.Label(
        "Hello, Android!",
        style=Pack(padding=(0, 10))
    )
    button = toga.Button(
        "Press Me",
        on_press=button_handler,
        style=Pack(padding=20)
    )
    box.add(label)
    box.add(button)
    return box
class MyApp(toga.App):
    def startup(self):
        self.main_window = toga.MainWindow(title=self.formal_name)
        self.main_window.content = build(self)
        self.main_window.show()
if __name__ == '__main__':
    MyApp().main_loop()

To Build for Android: BeeWare uses a tool called Briefcase.

  1. Install Briefcase: pip install briefcase
  2. Create a new Toga app: briefcase new
  3. Build for Android: briefcase build android
  4. Create the project: briefcase create android
  5. Run the app: briefcase run android

Best for: Developers who want a Python app that looks and feels like a native Android app without writing Kotlin/Java.


Chaquopy (Android Studio Plugin)

This is a completely different approach. Instead of a cross-platform framework, Chaquopy is a plugin for Android Studio. It allows you to mix Python code directly into a standard Android project.

How it Works: You create a standard Android project in Android Studio (using Kotlin or Java). You then add the Chaquopy plugin, which lets you:

  1. Add Python modules to your project.
  2. Call Python functions from your Java/Kotlin code.
  3. Call Java/Kotlin methods from your Python code.

The "API" for Android Interaction: The API is a two-way bridge between your Java/Kotlin world and your Python world.

Key Features:

  • Seamless Integration: Works within the standard Android development environment.
  • Access to Full Android SDK: Your Python code can directly access any part of the Android SDK through the Java bridge.
  • Use Python Libraries: You can easily include any Python library (e.g., NumPy, Pandas, TensorFlow) in your Android app.
  • Commercial: Chaquopy is a commercial product with a free version that has some limitations.

Example of Java -> Python:

// In your Android Activity (e.g., MainActivity.java)
import com.chaquo.python.PyObject;
import com.chaquo.python.Python;
public class MainActivity extends AppCompatActivity {
    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);
        Python py = Python.getInstance();
        PyObject pyObject = py.getModule("my_python_module"); // my_python_module.py
        String result = pyObject.callAttr("get_greeting").toString();
        Log.d("PythonResult", result); // Logs "Hello from Python!"
    }
}

Example of Python -> Java:

# In my_python_module.py
def get_greeting():
    # Get an Android context from the Java layer
    from android.content import Context
    from com.chaquo.python.android import pyroid
    context = pyroid.context
    # Use the context to get a string resource
    return context.getString(com.example.myapp.R.string.app_name)

Best for: Existing Android teams that want to add specific Python functionality (like data science, machine learning inference, or scripting) to their native apps without rewriting the entire app in Python.


Pydroid 3 (Educational & Development Environment)

Pydroid 3 is an Integrated Development Environment (IDE) for Python on Android itself. You install it from the Google Play Store, and it allows you to write and run Python code directly on your Android device.

How it Works: It's a complete Python environment on your phone or tablet. It comes with pre-installed libraries and has a package manager to install others (like NumPy, SciPy, Matplotlib, etc.).

The "API" for Android Interaction: Pydroid 3 has its own API to access basic Android features like sensors, camera, and files.

Key Features:

  • On-Device Development: Write and run Python code directly on your Android device.
  • Easy Library Installation: Simple pip-like interface to install scientific and other libraries.
  • Focus on Education/Science: Great for learning Python or for on-the-go scientific computing.

Best for: Learning Python, on-device scripting, light scientific computing, and educational purposes. It is not for building distributable Android apps.


Summary Table

Feature Kivy BeeWare (Toga) Chaquopy Pydroid 3
Primary Goal Cross-platform apps with custom UI Cross-platform apps with native UI Embed Python in native Android apps On-device Python development
UI Approach Custom OpenGL widgets Native platform widgets N/A (uses host app's UI) N/A (code editor / console)
Dev Environment Buildozer (CLI) Briefcase (CLI) Android Studio Pydroid 3 App (Play Store)
Android Access android module, jnius bridge Abstracted via Toga Direct Java/Kotlin bridge Pydroid 3's custom API
License Open Source (MIT) Open Source (Apache 2.0) Commercial (Free tier) Open Source (GPLv3)
Best For Games, graphics-heavy apps Apps needing native look-and-feel Adding ML/data science to native apps Learning, on-device scripting

Which One Should You Choose?

  • If you want to build a full-featured app and want it to look like a standard Android app: Choose BeeWare.
  • If you want to build a game or an app with a highly custom UI: Choose Kivy.
  • If you are an Android developer and want to add Python for data science or ML: Choose Chaquopy.
  • If you want to learn Python or run scripts directly on your phone: Choose Pydroid 3.
