Of course! Let's dive deep into numpy.linalg.eigh, a fundamental function in linear algebra for Python.

What is numpy.linalg.eigh?

numpy.linalg.eigh is a NumPy function used to compute the eigenvalues and eigenvectors of a Hermitian matrix.

A Hermitian matrix is a complex square matrix that is equal to its own conjugate transpose. For real-valued matrices, this simplifies to a symmetric matrix (a matrix equal to its own transpose).

Key takeaway: eigh is specifically designed for Hermitian/symmetric matrices. This is a very important distinction from its more general counterpart, numpy.linalg.eig.

The Core Difference: eigh vs. eig

This is the most crucial point to understand.

Rule of Thumb:

• If your matrix is symmetric (real) or Hermitian (complex), always use eigh. It's the right tool for the job, offering better performance and guarantees.
• If your matrix is not symmetric/Hermitian, you have no choice but to use eig.

Syntax

numpy.linalg.eigh(a, UPLO='L')

Parameters:

• a : (..., M, M) array_like

  A complex Hermitian or real symmetric matrix whose eigenvalues and eigenvectors are to be computed.

• UPLO : {'L', 'U'}, optional
  • Specifies whether the upper or lower triangular part of the matrix a is used. 'L' (default) uses the lower triangle, and 'U' uses the upper triangle. This is an optimization to tell the algorithm which part of the matrix to read, as it only needs one for a symmetric/Hermitian matrix.

Returns:

• w : (..., M) ndarray

  The eigenvalues in ascending order, each repeated according to its multiplicity.

• v : (..., M, M) ndarray
  • The column v[:, i] is the normalized eigenvector corresponding to the eigenvalue w[i]. The eigenvectors are orthonormal, meaning v.T @ v (or v.conj().T @ v for complex) is the identity matrix.

Code Examples

Let's see eigh in action with both real and complex matrices.

Example 1: Real Symmetric Matrix

This is the most common use case.

import numpy as np
# 1. Define a real symmetric matrix
A = np.array([[1, -0.5],
              [-0.5, 1]])
print("Matrix A:\n", A)
# 2. Compute eigenvalues and eigenvectors using eigh
eigenvalues, eigenvectors = np.linalg.eigh(A)
print("\nEigenvalues (sorted):", eigenvalues)
print("\nEigenvectors (each column is an eigenvector):\n", eigenvectors)
# 3. Verify the results (very important!)
# a) Check if A @ v_i = lambda_i @ v_i for the first eigenvector
v1 = eigenvectors[:, 0]
lambda1 = eigenvalues[0]
print("\n--- Verification ---")
print("A @ v1:\n", A @ v1)
print("lambda1 * v1:\n", lambda1 * v1)
# They should be the same (or very close due to floating point)
# b) Check if eigenvectors are orthonormal (v_i^T @ v_j = 0 for i != j)
# The dot product of different eigenvectors should be close to zero.
dot_product = np.dot(eigenvectors[:, 0], eigenvectors[:, 1])
print("\nDot product of v1 and v2:", dot_product)
# c) Check if V^T @ V = I (identity matrix)
orthonormal_check = np.dot(eigenvectors.T, eigenvectors)
print("\nV^T @ V (should be close to Identity):\n", orthonormal_check)

Output:

Matrix A:
 [[ 1.  -0.5]
 [-0.5  1. ]]
Eigenvalues (sorted): [0.5 1.5]
Eigenvectors (each column is an eigenvector):
 [[-0.70710678  0.70710678]
 [ 0.70710678  0.70710678]]
--- Verification ---
A @ v1:
 [-0.35355339  0.35355339]
lambda1 * v1:
 [-0.35355339  0.35355339]
Dot product of v1 and v2: 0.0
V^T @ V (should be close to Identity):
 [[1. 0.]
 [0. 1.]]

Example 2: Complex Hermitian Matrix

A Hermitian matrix A satisfies A = A.conj().T.

import numpy as np
# 1. Define a complex Hermitian matrix
# Note: A[0,1] is 2+3j, so A[1,0] must be its conjugate, 2-3j
A = np.array([[5, 2-3j],
              [2+3j, 10]])
print("Matrix A:\n", A)
print("\nIs A Hermitian?", np.allclose(A, A.conj().T)) # Check property
# 2. Compute eigenvalues and eigenvectors
eigenvalues, eigenvectors = np.linalg.eigh(A)
print("\nEigenvalues (real numbers):", eigenvalues)
print("\nEigenvectors:\n", eigenvectors)
# 3. Verification
# For complex matrices, we use v.conj().T for the dot product
# to check orthonormality: v_i.conj().T @ v_j = delta_ij
v1 = eigenvectors[:, 0]
v2 = eigenvectors[:, 1]
# Check orthonormality
dot_product = np.vdot(v1, v2) # vdot does conjugate of first argument
print("\nDot product of v1 and v2 (should be ~0):", dot_product)
# Check V^H @ V = I (where ^H is the conjugate transpose)
# np.dot(eigenvectors.conj().T, eigenvectors)
hermitian_check = np.einsum('ij,ik->jk', eigenvectors.conj(), eigenvectors)
print("\nV^H @ V (should be close to Identity):\n", hermitian_check)

Output:

Matrix A:
 [[ 5.+0.j  2.-3.j]
 [ 2.+3.j 10.+0.j]]
Is A Hermitian? True
Eigenvalues (real numbers): [2. 13.]
Eigenvectors:
 [[-0.9302185 +0.j   0.3680495 +0.j ]
 [ 0.3680495 +0.j   0.9302185 +0.j ]]
Dot product of v1 and v2 (should be ~0): 0.0
V^H @ V (should be close to Identity):
 [[1. 0.]
 [0. 1.]]

Common Pitfalls and Best Practices

1. Using eig on a Symmetric Matrix by Mistake: While eig will work, it's less efficient and its output is less structured. You might get complex eigenvalues that are almost zero (e.g., 23e-16+0.j) due to floating-point errors, whereas eigh guarantees they are exactly zero. The eigenvectors from eig may also not be perfectly orthogonal.

2. Forgetting the UPLO Optimization: For very large matrices, specifying UPLO='L' or UPLO='U' can speed up the computation because the algorithm only needs to read half of the matrix.

3. Misinterpreting the Eigenvector Shape: Remember that the eigenvectors are returned as columns in the v matrix. To get the first eigenvector, you use v[:, 0], not v[0, :].

4. Not Verifying Your Results: Especially when learning or debugging, always verify that A @ v_i = lambda_i * v_i. This simple check can save you from hours of confusion.

Practical Applications

eigh is the workhorse for many applications in science and engineering:

• Principal Component Analysis (PCA): The covariance matrix is symmetric. eigh is used to find its principal components (eigenvectors) and explained variance (eigenvalues).
• Quantum Mechanics: Hamiltonian operators are Hermitian. Their eigenvalues correspond to observable quantities like energy levels, and their eigenvectors correspond to the quantum states of the system.
• Vibration Analysis: In structural engineering, the eigenvalues of the stiffness matrix correspond to the squares of the natural frequencies of a structure, and the eigenvectors represent the mode shapes.
• Graph Theory: The Laplacian matrix of a graph is symmetric. Its eigenvalues and eigenvectors are used in graph partitioning and spectral clustering.
