Of course! Let's dive deep into UIAutomator for Python.

This is a very common requirement for Android automation. Here's a complete guide covering what it is, why you'd use it, how to set it up, and how to write scripts with clear examples.

What is UIAutomator?

UIAutomator is a UI testing framework for Android. It allows you to test user interfaces and perform operations like clicks, swipes, and text entry on your Android device or emulator from an external script.

Key Characteristics:

• Cross-App: It can interact with any application on the device, not just the one being tested. This is great for tasks like launching a dialer from your app or checking system notifications.
• View-Based: It interacts with UI elements based on their View properties, such as text, resource-id, content-description, and class. This is more stable than using coordinates, which can change with different screen resolutions.
• Java/Kotlin Origins: UIAutomator was originally part of the Android SDK and written in Java. The Python community has created excellent libraries to wrap this Java functionality, making it accessible to Python developers.

Why Use UIAutomator with Python?

You would choose UIAutomator for Python when you need to:

• Perform End-to-End (E2E) Testing: Automate a complete user flow, from app launch to a final confirmation.
• Interact with System UI: Click on notifications, toggle system settings, interact with the launcher, etc.
• Write Scripts for Complex Scenarios: For tasks like installing an APK, running your app, and then verifying its behavior.
• Leverage Python's Ecosystem: Use Python's powerful libraries for data analysis (pandas), reporting (pytest-html), or task scheduling (cron/APScheduler).

The Main Python Libraries for UIAutomator

There are two primary libraries you'll encounter. For new projects, uiautomator2 is the recommended choice.

Recommendation: Start with uiautomator2. It's the future-proof and more user-friendly option.

Step-by-Step Guide with uiautomator2

This is the most common and recommended workflow.

Step 1: Prerequisites

1. Python: Ensure you have Python 3.6+ installed.
2. Android Device or Emulator:
   • Device: Enable "USB Debugging" in Developer Options.
   • Emulator: Create an Android Virtual Device (AVD) in Android Studio with Google Play Services.
3. ADB (Android Debug Bridge): Make sure adb is in your system's PATH and can see your device. You can test this by running adb devices in your terminal. You should see your device/emulator listed.

Step 2: Installation

Install the uiautomator2 library using pip.

pip install --pre uiautomator2

Step 3: Initial Setup on the Device

This is the most crucial step. You need to install a helper APK on your device/emulator that will act as a bridge between your Python script and the Android UI.

Run the following command in your terminal:

python -m uiautomator2 init

This command will:

1. Check for a connected device.
2. Push the uiautomator2 helper APK to your device.
3. Install it.
4. Grant the necessary permissions.

You should see output similar to this:

[INFO] uiautomator2 version 2.16.21
[INFO] install apk: /Users/user/.pyenv/versions/3.9.6/lib/python3.9/site-packages/uiautomator2/inject/__pycache__/uiautomator2-2.16.21-py3-none-any.whl
[INFO] installed version: 2.16.21
...
[INFO] init success

Step 4: Your First Python Script

Now you can write Python code to control your device!

Connect to the device:

import uiautomator2 as u2
# Connect to the device via USB (or WiFi, see next section)
d = u2.connect()
# Or for a specific device serial
# d = u2.connect("emulator-5554")
print("Device connected successfully!")
print(f"Device name: {d.info['productName']}")
print(f"Screen resolution: {d.info['displayWidth']}x{d.info['displayHeight']}")

Performing Actions (Examples):

Let's automate a simple sequence: opening the Settings app, finding "About phone", and clicking it.

import uiautomator2 as u2
import time
# Connect to the device
d = u2.connect()
print("Starting automation script...")
# 1. Launch the Settings app
print("Launching Settings app...")
d.app_start("com.android.settings")
time.sleep(3) # Wait for the app to load
# 2. Find and click the "About phone" element
# We can find it by its text.
print("Finding 'About phone'...")
about_phone_element = d(text="About phone")
# Check if the element exists before clicking
if about_phone_element.exists:
    print("Element found. Clicking it...")
    about_phone_element.click()
    time.sleep(2)
    print("Successfully clicked 'About phone'.")
else:
    print("Error: 'About phone' element not found!")
# 3. Get the text of the "Model number" field
print("Getting model number...")
model_number_element = d(text="Model number")
if model_number_element.exists:
    # The actual value is in the sibling element
    model_value = model_number_element.sibling(className='android.widget.TextView').get_text()
    print(f"Model Number: {model_value}")
# 4. Go back to the previous screen
print("Pressing back button...")
d.press("back")
# 5. Stop the Settings app
print("Stopping Settings app...")
d.app_stop("com.android.settings")
print("Script finished.")

Advanced uiautomator2 Features

A. Connecting over WiFi

For faster execution, you can connect your device over WiFi after the initial USB setup.

1. Make sure your device and computer are on the same WiFi network.
2. On your device, open the UIAutomator2 app (it was installed in the init step).
3. Note the IP address displayed in the app (e.g., 168.1.10:5555).
4. Connect from Python using this IP:

import uiautomator2 as u2
# Connect using the IP:PORT from the app
d = u2.connect("http://192.168.1.10:5555")

B. Screen Recording

It's incredibly useful to record your script's execution to debug failures.

import uiautomator2 as u2
import time
d = u2.connect()
# Start recording
d.screenrecord.start("my_recording.mp4")
# --- Your automation steps here ---
d.app_start("com.android.settings")
d(text="About phone").click()
time.sleep(3)
# -------------------------------
# Stop recording. The video file will be on your computer.
video_path = d.screenrecord.stop()
print(f"Recording saved to: {video_path}")

C. Handling Toast Messages

Toast messages are those small pop-ups that appear at the bottom of the screen.

# Enable toast detection (must be called before toasts appear)
d.toast.show_debug = True # Shows toasts in logcat
d.toast.reset() # Clear any previous toasts
# Perform an action that might show a toast
d.press("home")
d(resourceId="com.android.launcher:id/search_button").click()
# Wait for a specific toast message to appear
try:
    # Wait up to 10 seconds for the toast
    toast_message = d.toast.get_message(10, default=None)
    if toast_message:
        print(f"Found Toast: {toast_message}")
    else:
        print("Toast message did not appear.")
except Exception as e:
    print(f"Error getting toast: {e}")
# Clear the toast message from the buffer
d.toast.reset()

Finding Element Selectors

The key to robust automation is finding the right elements. Here are the common ways to do it with uiautomator2.

You can use d.dump_hierarchy() to print the current UI layout to your console, which is great for finding resource-ids and other properties.

Pro-Tip: Use the uiautomator2 helper app on your device to easily inspect elements and get their resource-id, text, and other properties.
