Of course! Let's dive deep into numpy.linalg.svd(), the primary function for Singular Value Decomposition (SVD) in Python.

What is SVD?

Singular Value Decomposition is a fundamental matrix factorization technique in linear algebra. It breaks down any matrix A (of size m x n) into three other matrices:

A = U Σ Vᵀ

Let's break down each component:

1. U (Left Singular Vectors):


   （图片来源网络，侵删）
   • An m x m unitary matrix (orthonormal columns).
   • Its columns are the eigenvectors of the matrix A Aᵀ.
   • They represent the "output" basis vectors or the principal directions in the row space of A.

2. Σ (Sigma - Singular Values):

   • An m x n rectangular diagonal matrix.
   • The diagonal entries (where r is the rank of A) are called the singular values.
   • These values are always non-negative and are typically arranged in descending order (σ₁ ≥ σ₂ ≥ ... ≥ σᵣ > 0).
   • They are the square roots of the non-zero eigenvalues of both A Aᵀ and Aᵀ A.
   • The singular values represent the "magnitude" or "importance" of each corresponding singular vector.

3. Vᵀ (Right Singular Vectors):

   • An n x n unitary matrix (orthonormal columns). Vᵀ is the transpose of V.
   • Its columns are the eigenvectors of the matrix Aᵀ A.
   • They represent the "input" basis vectors or the principal directions in the column space of A.

numpy.linalg.svd()

This function is the workhorse for performing SVD in NumPy.

Syntax

import numpy as np
U, s, Vh = np.linalg.svd(a, full_matrices=True, compute_uv=True, hermitian=False)

Parameters

• a (array_like): The input matrix, a real or complex array of shape (M, N).
• full_matrices (bool, optional):
  • If True (default), U and Vh have shapes (M, M) and (N, N) respectively.
  • If False, U and Vh have shapes (M, K) and (K, N) respectively, where K = min(M, N). This is more memory-efficient for large, non-square matrices.
• compute_uv (bool, optional):
  • If True (default), it returns U, s, and Vh.
  • If False, it only returns the singular values s. This can be faster if you only need the singular values.
• hermitian (bool, optional):
  • If True, a is assumed to be Hermitian (symmetric if real-valued), and the algorithm is optimized for this case. This can be significantly faster.

Return Values

The function returns three arrays: U, s, and Vh.

1. U: Unitary matrix of shape (M, M) or (M, K).
2. s: The singular values, sorted in descending order. This is a 1-D array, not the full diagonal matrix .
3. Vh: Unitary matrix of shape (N, N) or (K, N). This is Vᵀ.

Important Note: The singular values s are returned as a 1-D array. To reconstruct the diagonal matrix , you need to create a zero matrix of the correct shape and place s on its diagonal.

Practical Examples

Example 1: Basic SVD and Reconstruction

Let's decompose a simple matrix and then reconstruct it to verify the decomposition.

import numpy as np
# The original matrix
A = np.array([[1, 2, 3],
              [4, 5, 6],
              [7, 8, 9],
              [10, 11, 12]])
print("Original Matrix A:\n", A)
# Perform SVD
U, s, Vh = np.linalg.svd(A)
print("\nU matrix:\n", U)
print("\nSingular values (s):\n", s)
print("\nVh matrix (V transpose):\n", Vh)
# --- Reconstruction ---
# Create the Sigma matrix from the singular values 's'
# The shape of Sigma should be (m, n)
m, n = A.shape
Sigma = np.zeros((m, n))
# Place the singular values on the diagonal
Sigma[:n, :n] = np.diag(s) # For a non-square matrix, this works well
# Reconstruct A
A_reconstructed = U @ Sigma @ Vh
print("\nReconstructed Matrix A:\n", A_reconstructed)
# Check if the reconstruction is accurate (within floating-point precision)
print("\nIs reconstruction close to original?", np.allclose(A, A_reconstructed))

Example 2: Using full_matrices=False

For a non-square matrix like A (4x3), full_matrices=True gives us a 4x4 U and a 3x3 Vh. We can save memory by using full_matrices=False.

U_small, s_small, Vh_small = np.linalg.svd(A, full_matrices=False)
print("Shape of U with full_matrices=False:", U_small.shape)  # Output: (4, 3)
print("Shape of Vh with full_matrices=False:", Vh_small.shape) # Output: (3, 3)
# The reconstruction is still the same
Sigma_small = np.diag(s_small)
A_reconstructed_small = U_small @ Sigma_small @ Vh_small
print("\nReconstruction with small matrices is accurate:", np.allclose(A, A_reconstructed_small))

Example 3: Image Compression (A Classic SVD Application)

SVD is powerful for compression because the singular values often decay rapidly. We can keep only the top k singular values and their corresponding vectors to create a low-rank approximation of the original matrix.

import matplotlib.pyplot as plt
from skimage import data
# Load a sample image (a grayscale astronaut image)
image = data.astronaut()
image_gray = np.mean(image, axis=2) # Convert to grayscale
# Perform SVD
U, s, Vh = np.linalg.svd(image_gray)
# Choose the number of components (k) to keep
k = 50
# Create a low-rank approximation
# We take the first k columns of U, first k singular values, and first k rows of Vh
image_compressed = U[:, :k] @ np.diag(s[:k]) @ Vh[:k, :]
# Display the results
fig, axes = plt.subplots(1, 2, figsize=(12, 6))
axes[0].imshow(image_gray, cmap='gray')
axes[0].set_title("Original Image")
axes[0].axis('off')
axes[1].imshow(image_compressed, cmap='gray')
axes[1].set_title(f"Compressed Image (k={k})")
axes[1].axis('off')
plt.show()
# Calculate the compression ratio
original_size = image_gray.shape[0] * image_gray.shape[1]
compressed_size = U[:, :k].shape[0] * U[:, :k].shape[1] + \
                  k + \
                  Vh[:k, :].shape[0] * Vh[:k, :].shape[1]
compression_ratio = original_size / compressed_size
print(f"Original size: {original_size} elements")
print(f"Compressed size: {compressed_size} elements")
print(f"Compression ratio: {compression_ratio:.2f}x")

Example 4: Solving a Linear System (Pseudo-Inverse)

For a non-square or singular matrix, the standard inverse doesn't exist. SVD provides a way to compute the Moore-Penrose Pseudo-Inverse, A⁺, which is very useful for solving least-squares problems.

A⁺ = V Σ⁺ Uᵀ

Where is formed by taking the reciprocal of non-zero singular values and then transposing the result.

# An overdetermined system (more equations than unknowns)
# Ax = b, where A is 4x2 and b is 4x1
A_sys = np.array([[1, 2],
                  [3, 4],
                  [5, 6],
                  [7, 8]])
b_sys = np.array([10, 20, 30, 40])
# Solve using SVD and the pseudo-inverse
U_sys, s_sys, Vh_sys = np.linalg.svd(A_sys, full_matrices=False)
# Create the pseudo-inverse of Sigma
Sigma_pseudo = np.diag(1 / s_sys)
# Calculate the pseudo-inverse of A
A_pseudo_inv = Vh_sys.T @ Sigma_pseudo @ U_sys.T
# Solve for x
x_solution = A_pseudo_inv @ b_sys
print("Matrix A:\n", A_sys)
print("\nVector b:\n", b_sys)
print("\nSolution x (using SVD pseudo-inverse):\n", x_solution)
# Compare with numpy's built-in lstsq (least-squares solution)
x_lstsq, _, _, _ = np.linalg.lstsq(A_sys, b_sys, rcond=None)
print("\nSolution x (using np.linalg.lstsq):\n", x_lstsq)

Common Pitfalls and Key Takeaways

1. Vh is Vᵀ, not V: The function returns V transpose. If you need the matrix V itself, you must transpose the result: V = Vh.T.
2. s is 1-D: The singular values are returned as a flat array. You must manually construct the diagonal matrix for reconstruction.
3. Floating-Point Precision: Due to floating-point arithmetic, the reconstructed matrix might not be exactly the same as the original. Always use np.allclose(A, A_reconstructed) for comparison, not A == A_reconstructed.
4. Rank and Zero Singular Values: The number of non-zero singular values in s gives you the rank of the matrix A. This is a numerically stable way to find rank.
5. full_matrices: For large datasets, always consider full_matrices=False to save memory and computation time, especially if you only need the first few singular vectors.
